Description

  Price €UR

50mW / TEM00 multiline incl. Power Supply 230VAC compact switching P.S.

call factory for availibility

100mW / TEM00 multiline incl. Power Supply 230VAC compact switching P.S.

call factory for availibility

150mW-200mW / TEM 00 multiline incl Power Supply 230 VAC compact switching P.S.

call factory for availibility

300mW / TEM00 multiline incl. Power Supply 230 VAC compact switching P.S.

call factory for availibility

OPTION SL: singleline Littrow prisma (wavelength selector for singlelineuse)

call factory for availibility

OPTION TRANS: compact autotransformator 230/110VAC - 2000VA (open frame)

call factory for availibility

OPTION WHITELIGHT 100mW: complete tandem system with HENE polarized

call factory for availibility

OPTION FAN: additional Laser Head Fan, ready mounted

call factory for availibility

Description

Price -EUR- €

75....100mW continuous Power excellent RGB colorbalance 457nm...647nm COMPLETE SYSTEM WITH 230VAC compact switching P.S., LASERHEAD, COOLING FAN

call factory for availibility

Description

Price -EUR- -€-

Exportprice -US$-

* INNOVA is a registed trademark of COHERENT Inc. USA

This Lasersystem features the world class excellent of Ion-Laserperformance and reliability, and is a homage to the most advanced tungsten disk ceramic laser tube technology. With the dual valve gas pressure control and online display of the plasma pressure analyzer the tube can be accurately maintained in optimum conditions. With the high pressure gas tank, the tube can be refilled serveral 100 000 times to keep optimum tube operation. Auto activated getter cleans the tube. (compared to limited amount of ampull cracking in other laser models, dual valve pressure control with online pressure analyzer gives the highest comfort in long live and stable operation) COHERENT Modell-52 is configured in full analog discret components, all commercially availabe worldwide, giving you complete independent integrity to maintain and service your lasersystem. Additionally the laser system comes with detailed operation and service handbook with schematics, service guides together with a complete service kit.

• TECHNICAL DATAS
•                             Whitelight                    Argon
• Plasmatube:      NEW , 0 hours            NEW , 0 hours
• State of the art segmented tungsten disc ceramic tube Resonator: Ultrastable Composition Quarz rod construction
• Power:               4,5 Watt/CW               8 Watt/CW
• Wavelength:      457..647nm                 257..514nm
• Colorbalance:    Excellent high RED     Balanced Green/Blue
•                         IDEAL RGB White      514,488,476,472,457nm
• Divergency:        Highpower Balzersset  2 Mirror sets supplied
• /Beam dia.        1.5mrad / 1.5mm          0.8mrad, 1.8mrad / 1.2mm
• Polarization:      100:1 Vertical polarized
• Noise:               Lightregulation 0.5% /  Currentcontrol 1%
• Electrical:          3Phase 204VAC/32Amps. - Neutral - PE
• Cooling:             Water Flow 30°C max. 2.5gallons=10liter/min
• Dimensions:    P.S. 19", heigth 9"=23cm, depth 19"=48.3cm / ~25Kg
• HEAD 49.5"=125.7cm, heigth 5.5"=14cm, depth 8"=20.3cm /~25Kg
• OPTIONAL:     Single line Littrow prism wavelength selector on request
